Ford F150 OEM-Style Bed Lighting Kit (2015-2020)

$139.99

5.0 / 5.0 based on 13 reviews

SKU: 4580

Free ship

In Stock!

Include Power Extension Wiring?: No - I Don't Need it

Want to add OEM-Style Bed Lighting to your F-150? The Starkey Bed Lighting Kit adds a premium OEM-style cargo box lighting system to your 2015+ F-150 in minutes! This system gives you the quality that is normally only found in the factory while providing an easy-to-install system. Our kit is completely Plug-N-Play for some trucks – please be sure to determine if your truck is pre-wired before ordering by reading the instructions below!

2021+ F150 System Available – See SKU# 4781

Features and Benefits:

  • LED lamps come ready for a plug-and-play installation. Our LED lamps are IP67 rated making them completely waterproof against high-pressure water spray. Their UV-treated Polycarbonate lens makes them rugged and dependable. Lamps illuminate when you open the door or unlock the doors with your Key Fob, and fade to off automatically when the truck is started or doors are locked.
  • Included is a Plug-N-Play adapter that allows you to seamlessly connect your LED lights to the factory wiring harness. All trucks equipped with the Trailer Assist Lamp, as well as some trucks with a factory-installed tow package are completely Plug and Play. Please see below for instructions on how to determine if your truck is pre-wired!*
  • LEDs are a White 6000k color temperature. White perfectly matches the factory trailer assist lamp.
  • LED lamps, wiring, and a complete instruction manual are all included. This kit was specifically engineered to fit the 2015+ F-150!
  • Unlike the OEM Ford Kit, no trips to the dealership for BCM re-programming are necessary!
    • 2015-2020 Ford F-150**

    *Your truck must be pre-wired for the Y-Adapter to provide power to your Bed Lighting.

    To determine if your truck is pre-wired, check the C431 inline connector shown in our instruction manual and YouTube installation video. On at least one of the plugs, the following wires should be present:
    2015-2017 = Pin #6 (Black with Yellow Stripe) and Pin #7 (Purple) – Please note, there is a Brown wire with a Purple stripe that looks similar.
    2018-2020 = Pin #6 (Black with Yellow Stripe) and Pin #7 (White with Green Stripe) – Please note, there are TWO White with Green wires on one side. You must have BOTH.

    If they are not, you will also need Starkey #4572 Power Extension Wiring

    **In rare instances, some 2015 & 2020 trucks may have a black connector in place of the normal connector shown. This product will work with minor modifications – see instruction manual for details.

    What’s Included:

    • 2 – LED Lamps
    • Wiring Extensions for lamps
    • Plug-n-Play C431 Y-Adapter Harness
    • Detailed installation manual/video
    • 5-Year Limited Warranty

      Installation:

      • Installation difficulty = Very Easy
      • Installation time = 15 minutes
      • Tools required = Flathead screwdriver
